Battery Specs
Case size #1, 148mm length, 66MM Width, 105MM Height
Specifications and Dimensions
|
Part +
|
Voltage Pb Eq |
Polarity
|
WHr
|
A/HR Pb Eq |
CCA (A) |
Weight (KG) |
Weight (LBS) |
| LFX14A1-BS12 | 12V |  |
59.4 |
14 | 210 | 0.92 | 2.03 |
|---|---|---|---|---|---|---|---|
| LFX18A1-BS12 | 12V | |
79.2 | 18 | 270 | 1.06 | 2.34 |
| LFX18L1-BS12 | 12V |  |
79.2 | 18 | 270 | 1.06 | 2.34 |
Case size #2, 113mm length, 58MM Width, 89MM Height
Specifications and Dimensions
|
Part +
|
Voltage Pb Eq |
Polarity
|
WHr |
A/HR Pb Eq |
CCA (A) |
Weight (KG) |
Weight (LBS) |
|---|---|---|---|---|---|---|---|
| LFX07L2-BS12 | 12V | |
26.4 | 7 | 102 | 0.45 | 0.99 |
| LFX09A2-BS12 | 12V | |
39.6 |
9 | 135 | 0.62 | 1.37 |
| LFX09L2-BS12 | 12V | |
39.6 | 9 | 135 | 0.62 | 1.37 |
| LFX14A2-BS12 | 12V | |
52.8 | 14 | 210 | 0.70 | 1.54 |
| LFX14L2-BS12 | 12V | |
52.8 | 14 | 210 | 0.70 | 1.54 |
| LFX18A2-BS06 | 6V | |
39.6 | 18 | 270 | 0.60 | 1.32 |
| LFX18L2-BS06 | 6V | |
39.6 | 18 | 270 | 0.60 | 1.32 |
Case size #3, 166mm length, 86MM Width, 155MM Height
Specifications and Dimensions
|
Part +
|
Voltage Pb Eq |
Polarity
|
WHr
|
A/HR Pb Eq |
CCA (A) |
Weight (KG) |
Weight (LBS) |
|---|---|---|---|---|---|---|---|
| LFX24A3-BS12 | 12V | |
105.6 | 24 | 360 | 1.65 | 3.63 |
| LFX24L3-BS12 | 12V | |
105.6 |
24 | 360 | 1.65 | 3.63 |
| LFX27A3-BS12 | 12V | |
118.8 | 27 | 405 | 1.69 | 3.72 |
| LFX27L3-BS12 | 12V | |
118.8 | 27 | 405 | 1.69 | 3.72 |
| LFX36A3-BS12 | 12V | |
158.4 | 36 | 540 | 2.18 | 4.80 |
| LFX36L3-BS12 | 12V | |
158.4 | 36 | 540 | 2.18 | 4.80 |
Case size #4, 148mm length, 86MM Width, 88MM Height
Specifications and Dimensions
|
Part +
|
Voltage Pb Eq |
Polarity
|
W/HR
|
A/HR Pb Eq |
CCA (A) |
Weight (KG) |
Weight (LBS) |
|---|---|---|---|---|---|---|---|
| LFX14A4-BS12 | 12V | |
59.4 | 14 | 210 | 0.93 | 2.05 |
| LFX19A4-BS12 | 12V | |
84.5 | 19 | 285 | 1.12 | 2.47 |
Case size #5, 134mm length, 80MM Width, 160mm height
Specifications and Dimensions
|
Part +
|
Voltage Pb Eq |
Polarity
|
W/HR
|
A/HR Pb Eq |
CCA (A) |
Weight (KG) |
Weight (LBS) |
|---|---|---|---|---|---|---|---|
| LFX14A5-BS12 | 12V | |
59.4 | 14 | 210 | 1.07 | 2.36 |
| LFX14L5-BS12 | 12V | |
59.4 | 14 | 210 | 1.07 | 2.36 |
Case size #6, 148mm length, 82mm width, 140mm height
Specifications and Dimensions
|
Part +
|
Voltage Pb Eq |
Polarity
|
W/HR
|
A/HR Pb Eq |
CCA (A) |
Weight (KG) |
Weight (LBS) |
|---|---|---|---|---|---|---|---|
| LFX21A6-BS12 | 12V | |
92.4 | 21 | 315 | 1.36 | 3.00 |
| LFX21L6-BS12 | 12V | |
92.4 | 21 | 315 | 1.36 | 3.00 |
